IP66 SURFACE MOUNTED DOWNLIGHT
Choose your product version
118mm 35W
138mm 50W
168mm 70W
208mm 120W
IP66 Waterproof LED Surface Mounted Downlight
Modular Design allows free combination, easy for inventory and maintenance.
Product benefits
- Cut Out: 118mm
- Power：DIP Switch 25W 30W 35W
- DIP Swith Driver
- High Efficiency upto 110lm/W
- CRI 90
- Beam Angle: 15°/25°/36°/45°/60°
- CCT: Single 2700K ~ 6000K
- 5 Years Warranty
- Color: White RAL 9016, Black RAL 9005, Grey RAL 7040
IP66 Waterproof LED Surface Mounted Downlight
Modular Design allows free combination, easy for inventory and maintenance.
Product benefits
- Cut Out: 138mm
- Power：DIP Switch 35W 45W 50W
- DIP Swith Driver
- High Efficiency upto 120lm/W
- CRI 90
- Beam Angle: 15°/25°/36°/45°
- CCT: Single 2700K ~ 6000K
- 5 Years Warranty
- Color: White RAL 9016, Black RAL 9005, Grey RAL 7040
IP66 Waterproof LED Surface Mounted Downlight
Modular Design allows free combination, easy for inventory and maintenance.
Product benefits
- Cut Out: 138mm
- Power：DIP Switch 35W 45W 50W
- DIP Swith Driver
- High Efficiency upto 120lm/W
- CRI 90
- Beam Angle: 15°/25°/36°/45°
- CCT: Single 2700K ~ 6000K
- 5 Years Warranty
- Color: White RAL 9016, Black RAL 9005, Grey RAL 7040
IP66 Waterproof LED Surface Mounted Downlight
Modular Design allows free combination, easy for inventory and maintenance.
Product benefits
- Cut Out: 168mm
- Power：DIP Switch 50W 60W 70W
- DIP Swith Driver
- High Efficiency upto 120lm/W
- CRI 90
- Beam Angle: 15°/25°/36°/45°
- CCT: Single 2700K ~ 6000K
- 5 Years Warranty
- Color: White RAL 9016, Black RAL 9005, Grey RAL 7040
IP66 Waterproof LED Surface Mounted Downlight
Modular Design allows free combination, easy for inventory and maintenance.
Product benefits
- Cut Out: 208mm
- Power：DIP Switch 75W 100W 120W
- DIP Swith Driver
- High Efficiency upto 120lm/W
- CRI 90
- Beam Angle: 15°/25°/36°/45°
- CCT: Single 2700K ~ 6000K
- 5 Years Warranty
- Color: White RAL 9016, Black RAL 9005, Grey RAL 7040
MODULAR DESIGN
LED modules can be combined with various aluminum rings and bezels to create diverse appearances.
TECHNICAL DATA
VALUE
Luminaire colour
RAL9016 White，RAL9017 Black
Cut Out
98mm, 118mm, 138mm，168mm, 208mm, 258mm
Input Power
30W@φ98mm，35W@φ118mm，50W@φ138mm
70W@φ168mm，120W@φ208mm，180W@φ258mm
Input Voltage
220-240V
Luminous Efficacy
upto 110lm/W
LED Chip
Bridgelux COB
CCT
2700 / 3000 / 4000 / 5000 / 6000 / 6500K
CRI
>80Ra or >90Ra
Dimming
On-Off, Phase, 0/1-10V, DALI
Light Distribution Curve
15°，25°，36°，45°，60°
Ambient Temperature Ta ( @life time 50,000 h)
-25 ~ 40°
Rated Life L80/B50 @25°C
50,000 hrs
Warranty
5 years
